As a general rule, scan field should be from Carina to Sella turcica when patient is positioned properly. Be aware of diagnosis to ensure that all relevant anatomy is included. If patient is unable to position properly and a large portion of brain/skull will need to be scanned please clear with radiologist to ensure that no additional orders will need to be obtained

If with IV contrast, 100ml omni 300 scan at 45 seconds

Helical Supine: 2.5 x 2.0 GE standard / 2.0 x 2.0 Siemens standard

Recons: 1.25 x 0.625 GE standard / 1.0 x 0.7 Siemens standard

Reformats: 2.0 x 2.0 coronal standard

2.0 x 2.0 sagittal standard

8 x 8 MIPs axials through lungs ( 1600 width -300 level )

2.5 x 2.5 axial lung windows GE 1500 W -500 L/ 2.0 x 2.0 Siemens

SCAN FROM AORTIC ARCH TO SELLA TURCI

125 ml omnipaque 350 injected at 4cc/second. Bolus track on the Aortic Arch at 80 HU.

Helical: 2.5 x 2.0 GE standard / 2.0 x 2.0 Siemens standard 800 W 100 L

recons: 0.625 x 0.625 GE standard 400 W 40 L / 0.75 x 0.7 Siemens standard 400 W 40 L

1 x 1 mm 800 W 100 L

coronal MIP 14 x 4 GE / 16 x 4 Siemens 800 W 100 L

sagittal MIP 14 x 4 GE / 16 x 4 Siemens 800 W

oblique MIP of each carotid bifurcation to open up the “Y” 5 x 2 800 W 100 L

oblique arch MIP 5 x 2

coronal MPR 2 x 2 of carotids and head separately

sagittal MPR 2 x 2 of carotids and head separately

VRT of each carotid rotate and tumble every 10 degrees to show bifurcation

MIP rotate of each carotid every 10 degress 800 W 100 L

VRT of COW rotate and tumble every 10 degrees
